flange facers
AFF0/1200
AFF150/1500
AFF150/1500
SPECIFICATIONS
- Facing Diameter: 0 - 1200mm.
- POWER: 5HP Electric or Optional: Hydraulic(5HP)
- Cutting Method: Single Point Cutting Tools.
- Features: Machines offers versatile repair capabilities to a wide range of plant and equipment single point cutting tool. Typical applications include the re-facing of pipeline flanges and connectors ranging from gramophone finished raised faces to precision O-ring grooves. With the addition of easy to install, bolt-on “kits” the machining centres may be adapted to repair RTJ grooves, to machine valve seats and to produce bores.
AFF150/1500
AFF150/1500
AFF150/1500
SPECIFICATIONS
- Flange Bore Minimum: 90mm
- Facing Diameter: 150 - 1500mm.
- Cutting Method: Single / Multi Point Cutting Tools.
- POWER: 3HP Electric or Optional: Hydraulic(5HP)
- Features: Machines offers versatile repair capabilities to a wide range of plant and equipment. Typical applications include the re-facing of pipeline flanges and connectors ranging from gramophone finished raised faces to precision O-ring grooves. With the addition of easy to install, bolt-on “kits” the machining centres may be adapted to repair RTJ grooves, to machine valve seats and to produce bores.
AFF1500/8000
AFF1500/8000
AFF1500/8000
.jpg/:/cr=t:16.69%25,l:0%25,w:100%25,h:66.63%25/rs=w:1066,h:533,cg:true)
SPECIFICATIONS
- Flange Bore Minimum: 1500mm
- Facing Diameter: 1500 - 8000mm.
- Cutting Method: Single / Multi Point Cutting Tools.
- POWER: 5HP Electric or Optional: Hydraulic(15HP)
- Features: Machines offers versatile repair capabilities to a wide range of plant and equipment. Typical applications include the re-facing of pipeline flanges and connectors ranging from gramophone finished raised faces to precision O-ring grooves. With the addition of easy to install, bolt-on “kits” the machining centres may be adapted to repair RTJ grooves, to machine valve seats and to produce bores.
AFF1500/8000
AFF1500/8000
AFF1500/8000
SPECIFICATIONS
- Flange Bore Minimum: 2000mm
- Facing Diameter: 2.5 - 40meters.
- Cutting Method: Multi Point Cutting Tools.
- POWER: Hydraulic 25HP
- Features: NC based self aligned machining can cover wide reange of Slew ring bearing seating, under carriage bearing seating,
